Number of Ways	2-way
Pressure Range	-0.95 - 60 bar
Accuracy Class	0.5 (+/-0.5 %)
Pressure Scale	MPa \| bar \| kPa \| kg/cm2 \| psi
Resolution	0.001 bar, 0.5 psi, 0.0001 MPa, 0.01 kg/cm2, 1 kPa
Temperature measuring range	-40 - +125°C
Temperature Accuracy	+/-1 K
Temperature Units	°C \| °F
Temperature Resolution	0.1 °C / 0.1 °F
Sensor Type	K-type \| Pirani Sensor \| Piezo Sensor
Refrigerant(s)	R11 \| R113 \| R114 \| R12 \| R123 \| R124 \| R13 \| R13B1 \| R134a \| R14 \| R22 \| R23 \| R32 \| R41 \| R125 \| R142b \| R152A \| R161 \| R170 \| R227ea \| R236ea \| R236fa \| R245fa \| R290 \| R401A \| R401B \| R401C \| R402A \| R402B \| R403B \| R404A \| R406A \| R407A \| R407B \| R407C \| R407D \| R407F \| R407H \| R408A \| R409A \| R410A \| R412A \| R413A \| R414B \| R416A \| R417A \| R420A \| R421A \| R422A \| R422B \| R422C \| R422D \| R424A \| R426A \| R427A \| R434A \| R437A \| R438A \| R442A \| R444A \| R445A \| R448A \| R449A \| R450A \| R452A \| R452B \| R453A \| R454A \| R454B \| R454C \| R455A \| R470A \| R470B \| R500 \| R502 \| R503 \| R507 \| R507A \| R508A \| R508B \| R513A \| R600 \| R600a \| R744 \| R1270 \| R1234yf \| R1233zd \| R1234ze \| R411A
Operating Temperature Range	-20 - 50°C
Storage Temperature Range	-20 - 60°C
Battery	4 x AA \| 2 x 2 AAA \| 3 x AAA \| Alternative Power Supply USB Mirco-B
Ingression Protection	IP42
Operating Hours	50 h at low operation
Gas Connection	1/4" SAE
Functions	Superheat / Subcool, Digital / analogue display, Slave pointer, Pressure zeroing, Data logging, Tube error compensation, Refrigerant favorites, Refrigerant update, Firmware update, Set pressure reference, Field calibration, Unit and language settings, Display brightness, Wireless connections, Commissioning date, Printscreens

Net Weight [kg]	1.05
Net Width [mm]	195
Net Height [mm]	75
Net Depth [mm]	195
Gross Weight [kg]	4.57
Gross Width [mm]	353
Gross Height [mm]	107
Gross Depth [mm]	526
Packing Weight [kg]	3.52
Customs Tariff Number	9026.2000
